505nm narrow-band filter

Narrowband filter main role is to make the specific wavelengths of light by reflection, let the other wavelengths of light (or decay) optical elements. Half wave width usually controlled to 20nm or less, ultraviolet, visible, near infrared wavelength, infrared band. Narrow band filter our company adopts multi-layer dural by ion assisted deposition of nano materials and high vacuum evaporation coating, good compactness, high image resolution.

關(guān)閉
產(chǎn)品咨詢
客服熱線：400-700-9997

Giai photonics Co.,Ltd

Product features:
Narrowband filter main role is to make the specific wavelengths of light by reflection, let the other wavelengths of light (or decay) optical elements. Half wave width usually controlled to 20nm or less, ultraviolet, visible, near infrared wavelength, infrared band. Narrow band filter our company adopts multi-layer dural by ion assisted deposition of nano materials and high vacuum evaporation coating, good compactness, high image resolution.

Optical index:

Wavelength: 515 ± 7Nm

Through rate: T=60%

Bandwidth: 20nm

Stop band 400nm-480nm

T <0.1

530nm-1100nm

Cutoff rate: T<0.1%

Advantage.

Hard coatings, long service life,

Wavelength positioning accuracy

Ion plating, small temperature drift

The penetration rate is high,

Cut-off depth

Field of application:

Fluorescence analyzer, microplate, cable TV upgrade equipment, wireless communication equipment, mobile phone bar code scanning, infrared electronic whiteboard, infrared camera, infrared touch screen, iris recognition, infrared medical instruments, infrared printing ink recognition, red film recognition, face recognition sensor system. Handheld infrared laser rangefinder, laser range finder, optical instrument, medical equipment and testing instruments.
